32 Pin High Density Connector Match Harting Han Connector Rectangular

Name: 32 Pin High Density Connector Match Harting Han Connector Rectangular
Brand: ZJHK
Price: 1 USD

Buy cheap 32 Pin High Density Connector Match Harting Han Connector Rectangular product

Brand Name : ZJHK

Model Number : HEE-032-MC

Certification : CE, RoHS, SGS, CQC,

Place of Origin : China

MOQ : 5

Price : Negotiable

Payment Terms : L/C, T/T, Western Union, Paypal

Supply Ability : 100,000 pcs per month

Delivery Time : 7 Days

Packaging Details : Standard Export Cartons

Order Num09320103101ber : 09320323001

Model Type : Standard Connector HEE Series

Material : Polycarbonate Sabic 3412 ECR

Wire Connection : CRIMP

Housing : H16B Series

Nos of Contact : 32 PIN

Contact Now

HEE 32 PIN CRIMP HEAVY DUTY CONNECTOR INSERT

With the introduction and development of Industry 4.0.

The demand for electrical connection in the machinery industry is getting higher and higher, which requires our products to develop in the direction of stabilization, convenience and customization.

Haoke heavy duty connector can fully meet your use in the machinery industry.

Technical data

Identification	Date	Unit
Series	HEE high density	series
Version	Part No.	09320323001
Termination method	Crimp TYPE
Number of contacts	32
Length	64	mm
Width	34.5	mm
Height	34	mm
Rate voltage	500	V
Rate current	16	Amp
Pollution degree	Three
Rate impulse voltage	6	KV
Insulation resistance	1010	Ω
Mechanical woking life	more than 500	Times
Contact resistance	≤1	mΩ
Min.connection capacity for solid wire	0.14/26	m㎡/AWG
Max.connection capacity for solid wire	4/12	m㎡/AWG
Min.connection capacity for strand wire	0.14/26	m㎡/AWG
Max.connection capacity for strand wire	4/12	m㎡/AWG
Material (insert)	Polycarbonate
Metal meterial	Copper alloy
Operating temperature	-40℃～+125℃
Stripping length	7.5	m

Deatils photo:

32 Pin High Density Connector Match Harting Han Connector Rectangular

Design details :

32 Pin High Density Connector Match Harting Han Connector Rectangular

Notice:

Please order crimp contacts separately.

Click here to check more series information:

Click here to back to Hompage check more series . → 32 Pin High Density Connector Match Harting Han Connector Rectangular

Product Tags:

32 Pin High Density Connector

Match Harting Han Connector

Rectangular Harting Han Connector
