Name: HE 006 Quick Lock Terminal Heavy Duty Rectangular Connectors Replace Phoenix Connector
Brand: ZJHK
Price: 1 USD

Brand Name : ZJHK

Model Number : HE-006-FZ

Certification : CE, RoHS, SGS, CQC,

Place of Origin : China

MOQ : 5

Price : Negotiable

Payment Terms : L/C, T/T, Western Union, Paypal

Supply Ability : 100,000 pcs per month

Delivery Time : 7 Days

Packaging Details : Standard Export Cartons

Order Number : 09330062901

Model Type : Standard Connector HE Series

Material : Polycarbonate Sabic 3412 ECR

Wire Connection : Quick Lock

Housing : H6B Series

Nos of Contact : 6

Contact Now

ZJHK HE-006-FZ

Inserts, Quck Lock termination, Female, Polycarbonate, Rated current: 16A, Size: 6 B, Contacts: 6, Conductor cross-section: 0.14 ... 2.5mm²,

ABB ROBOT BEST CHOICE

Technical data

Version
Termination method	Quck Lock termination
Gender	Female
Size	6B
With wire protection	Yes
Number of contacts	6
PE contact	Yes
Technical characteristics
Conductor cross-section	0.14 ... 2.5 mm²
Conductor cross-section	AWG 26 ... AWG 14
Rated current	16A
Rated voltage	500 V
Rated impulse voltage	6 kV
Rated voltage acc. to UL	600 V
Rated voltage acc. to CSA	600 V
Insulation resistance	> 10¹⁰ Ω
Contact resistance	≤ 1 mΩ
Limiting temperature	-40 ... +125 °C
Stripping length	7 ... 9 mm
Tightening torque	0.5 Nm
Mating cycles	≥ 500
Material properties
Material (insert)	Polycarbonate
Colour (insert)	RAL 7032 (pebble grey)
Material (contacts)	Copper alloy
Surface (contacts)	Silver plated
RoHS	compliant with exemption
Commercial data
Packaging size	1
Net weight	60g
Country of origin	China
eCl@ss	Contact insert for industrial connectors
