16amp Female Screw Terminal Heavy Duty Connector KUKA Industrial Solution 09330062701

Name: 16amp Female Screw Terminal Heavy Duty Connector KUKA Industrial Solution 09330062701
Brand: ZJHK
Price: 1 USD

Buy cheap 16amp Female Screw Terminal Heavy Duty Connector KUKA Industrial Solution 09330062701 product

Brand Name : ZJHK

Model Number : HE-006-F

Certification : CE, RoHS, SGS, CQC,

Place of Origin : China

MOQ : 5

Price : Negotiable

Payment Terms : L/C, T/T, Western Union, Paypal

Supply Ability : 100,000 pcs per month

Delivery Time : 7 Days

Packaging Details : Standard Export Cartons

Order Number : 09330062701

Model Type : Standard Connector HE Series

Material : Polycarbonate Sabic 3412 ECR

Wire Connection : Screw

Housing : H6B Series

Nos of Contact : 6

Contact Now

Replace Han E 06 Pos. F Insert Screw

Inserts, Screw termination, Female, Polycarbonate, RAL 7032 (pebble grey), Rated current: 16A, Size: 6 B, Contacts: 6, Conductor cross-section: 0.75 ... 2.5mm², Copper alloy, Silver plated

Fit ABB KUKA FANUC Robots Industrial solution

Part number: 09330062701

Technical data

Identification
Category	Inserts
Series	HE
Termination method	Screw termination
Gender	Female
Size	6B
Number of contacts	6Pin
PE contact	Yes
Contact identification	0.75 ... 2.5 mm²
Conductor cross-section	AWG 18 ... AWG 14
Technical characteristics
Rated current	16A
Rated voltage	500V
Rated impulse voltage	6 kV
Rated voltage acc. to UL	600 V
Insulation resistance	≥ 10¹⁰ Ω
Limiting temperature	-40 ... +125 °C
Mating cycles	≥ 500
Material properties
Material (insert)	Polycarbonate
Colour (insert)	RAL 7032 (pebble grey)
RoHS	Compliant with exemption
Packaging size	1
Net weight	49g
eCl@ss	Contact insert for industrial connectors

16amp Female Screw Terminal Heavy Duty Connector KUKA Industrial Solution 09330062701

Our Services

1. We are professional supplier,so we provide Low MOQ: It can meet your business very well.

2. We work with dozens of factories to ensure competitive price, We also will treat you as our friends.

3. Inspections:100% test before delivery.Package will do after several discussions with you.

4. OEM and ODM are acceptable,Please send us your design and other important information. OEM are always welcome.

Any questions please feel free to contact us, 7*24 hours for you !!!
